Mixers AGF

Mixers AGF Stationary Mixer




Compact, simple, functional, it is ideal for the liquid mixing in the internal of tanks under pressure or air vacuumed. Every particular has been shrank and optimized to obtain the maximum efficiency and the maximum reliability in any condition and use.
Thanks to the standard motor, with AGF it is possible to personalize the mixing characteristics in terms of power, rotation speed as per the plant and product needs.



TECHNICAL FEATURES:
All the parts of the AGF stationary mixer coming into contact with the liquid are made of AISI 316 stainless steel. The pull-out shaft and paddles form a single unit which is rotated by the motor through a rigid connection or screwed joint. The accurate balancing of the coupling enables the total length of the machine to exceed 1.50 m.
In the standard version, the mechanical seal is internal, self-cooled and can be constructed of different materials to suit the chemical and physical properties of the liquid (the standard version offers a ceramic / graphite combination). The AGF stationary mixer is equipped with standard IP 55 motors. Therefore the power values and rpm’s given in the table below represent just one example of the vast range of combinations which can be made by just substituting one type of motor for another while all the other parts of the mixer remain unchanged.

MODEL
Power
(kW)
r.p.m.
Capacity of Tank
(m³)
AGF 037
0,37
920
2  -  7
AGF 055
0,55
920
7  -  10
AGF 075
0,75
920
10  -  15
AGF 11
1,1
920
15  -  20
AGF 15
1,5
920
20  -  35
AGF 22
2,2
935
35  -  60
AGF 30
3
960
50  -  70
AGF 40
4
960
70  -  100
AGF 55
5,5
960
80  -  120



PERFORMANCE:
DRINKS INDUSTRY:Wine, grape must, juices, beer, alcoholic drinks, cordials
FOOD INDUSTRY:Oil, sugar solutions, vinegar, mustard
LIQUID WASTE TREATMENT:Spent oils, effluent, coolants
CHEMICAL INDUSTRY:Acids, dispersing media, detergents, inks
PHARMACEUTICAL INDUSTRY:Emulsion, liquid soaps
PAINT INDUSTRY:Paints, solvents, glues
